High on your list for low heat gain

SunGuard® SuperNeutral (SN) 62/34 is a high selectivity products that combines very high natural light transmission while ensuring energy savings through solar protection and thermal insulation. With a neutral transmitted and reflected colour, the product is ideal for full facade glazing and roof glazing. SN 62/34 is available in heat-treatable and annealed forms, offering similar performances and appearance uniformity.

Product information

Substrates
  • Guardian ExtraClear 4-12 mm
  • Guardian UltraClear 4-12 mm
Applications
  • Windows
  • Facades
  • Roof window
  • Curtain walls
  • Doors
Manufacturing Options
  • TPF (Temporary Protective Film)
  • Annealed
  • Dual Product (Annealed and Heat Treated versions)
  • Must be Heat Treated
  • Laminated
  • Bent
Recommended Coating Positions
  • Surface 2 (double IGU)
  • Surface 2 Triple IGU
Maximum Size
  • <3210x6000mm
Edge Deletion
  • Yes
Glass Type
  • Double Silver Coated Glass
Glass Functions
  • Solar control
  • Thermal insulation
Fabrication Options
  • Must be used in an Insulating Glass Unit
Appearance
  • Neutral

Visual Appearance

Use the Glass Visualizer to get an introductory understanding of how glass will appear in use. Use the Glass Analytics tools to explore even more options for color and performance.

Choose an option
There is only one substrate available for this product

View

This tool intended to represent the reflected/transmitted color ; however, glass color cannot be accurately portrayed online. For more information, launch the Glass Visualizer.

Original Image
Modified Image

You need more information and additional mockups? Consult our Glass Visualizer Tool:

Calculate Performance Values & Generate BIM Files
Generate product performance data for custom glass make-ups and create detailed BIM object files for your project
Calculate
Performance data

The glazing make-up suggestions below are pre-defined to provide examples of commonly used combinations of products. There are many other glass combinations available at Glass Analytics.

Double Glazed

pim/components/structure/pim-double

GLASS: Guardian ExtraClear (CE) Glass, 6mm (2-SunGuard® SN 62/34 (CE) - Discontinued)

GAP: 10% Air, 90% Argon 16.0mm

GLASS: Guardian ExtraClear (CE) Glass, 4mm

Calculated Values are in accordance with EN 410:2011 / EN 673:2011

Performance Values

Visible Light
Transmittance (τv)
63 %
Reflectance outside (ρv)
14 %
Reflectance inside (ρv)
17 %
General Color Rendering Index (CRI)
95
Ultraviolet
Transmittance UV (τuv)
20 %
Solar Energy
Solar transmittance (τe)
32 %
Reflectance outside (ρe)
37 %
Reflectance inside (ρe)
44 %
Solar absorptance (αe)
31 %
Solar Factor (g)
34 %
Shading Coefficient (sc)
0.39
Thermal properties
U-Value (Ug)
1.0 W/m²·K

Triple Glazed

pim/components/structure/pim-triple

GLASS: Guardian ExtraClear (CE) Glass, 6mm (2-SunGuard® SN 62/34 (CE) - Discontinued)

GAP: 10% Air, 90% Argon 14.0mm

GLASS: Guardian ExtraClear (CE) Glass, 4mm

GAP: 10% Air, 90% Argon 14.0mm

GLASS: Guardian ExtraClear (CE) Glass, 4mm (5-ClimaGuard® Premium2 (CE))

Calculated Values are in accordance with EN 410:2011 / EN 673:2011

Performance Values

Visible Light
Transmittance (τv)
56.9 %
Reflectance outside (ρv)
16.3 %
Reflectance inside (ρv)
19.9 %
General Color Rendering Index (CRI)
93.6
Ultraviolet
Transmittance UV (τuv)
12.3 %
Solar Energy
Solar transmittance (τe)
27.7 %
Reflectance outside (ρe)
38.5 %
Reflectance inside (ρe)
40.7 %
Solar absorptance (αe)
33.8 %
Solar Factor (g)
31.0 %
Shading Coefficient (sc)
0.36
Secondary Heat Transfer (qi)
3.2
Thermal properties
U-Value (Ug)
0.6 W/m²·K
