Performance data

The glazing make-up suggestions below are pre-defined to provide examples of commonly used combinations of products. There are many other glass combinations available at Glass Analytics.

Default Performance Data
Performance Calculations

Double Glazed

Double Glazed

GLASS: Guardian Clear Glass (Middle East & Africa) Glass, 6mm (2-SunGuard® HP Silver+ 40 (Middle East & Africa))

GAP: 100% Air 12.0mm

GLASS: Guardian Clear Glass (Middle East & Africa) Glass, 6mm

Calculated Values are in accordance with NFRC2010

Performance Values For more details on the performance values displayed and Embodied CO2 please click here

Visible Light

Transmittance (τv)

40 %

Reflectance outside (ρv)

31 %

Reflectance inside (ρv)

15 %

General Color Rendering Index (CRI)

91.4

Ultraviolet

Transmittance UV (τuv)

24 %

Solar Energy

Solar transmittance (τe)

23 %

Reflectance outside (ρe)

37 %

Reflectance inside (ρe)

31 %

Solar absorptance (αe)

41 %

Solar Heat Gain Coefficient (SHGC)

0.28

Shading Coefficient (sc)

0.32

Thermal properties

Winter night U-Value

1.695 W/m²·K

Summer day U-value

1.655 W/m²·K

Light to Solar Gain

Light to Solar Gain (LSG)

1.42

Embodied Co<sub>2</sub>

[eq. kg/m²] A1-A3

36.92

Performance Calculations

SunGuard® High Performance

HP Silver+ 40

Monolithic Not Laminated Monolithic Laminated Double Glazed Not Laminated Double Outer pane Laminated Double Inner pane Laminated Double Inner and Outer pane Laminated Triple Glazed Not Laminated Triple Outer pane Laminated Triple Inner pane Laminated Triple Inner and Outer pane Laminated

With the performance calculator, you can quickly calculate the performance data that matches your own glazing make-up
